Fanatec ClubSport Pedals V3 inverted

💥 Features 💥
🔹 Turning points of brake and clutch on top side like in real cars
🔹 High-resolution pedals with magnetic and contactless sensors on gas and clutch for a long life and maximum performance
🔹 Pressure sensitive brake with custom made 90 kg load cell sensor
🔹 Adjustable brake stiffness and travel without tools
🔹 12-bit resolution (4096 values) on all axis
🔹 Alternative D-shape race plates in curved design
🔹 Pedal extension to adjust the angle of the pedal plate and to change the angle of the whole pedal arm
🔹 Brake sensitivity can be adjusted through the Tuning Menu of the wheel and during the race
🔹 Vibration motor on throttle pedal indicates rear wheel spin and oversteer (control by games is possible via Fanatec Wheel SDK)
🔹 Vibration motor on brake pedal to simulate ABS and indicate locking tires (controlled by Fanatec wheels: Compatible to all games. Dynamic control by games is possible via Fanatec Wheel SDK)
🔹 Design of the gas pedal allows quick exchange of the springs. Two springs of different strengths are included
🔹 Damper Kit assembled out-of-box on brake pedal, optional damper kit for gas sold separately. The hyraulic dampening resistance can easily be adjusted with a knob
🔹 Full multiplatform compatibility, depending solely on the platform compatibilities of the connected Wheel Base/Racing Wheel
🔹 Full metal construction of CNC-machined aluminium
🔹 Ultimate adjustability: Position of pedal plates in all directions, angle, spring strength at throttle, brake sensitivity, brake travel
🔹 Compatible with the Colour Kits to allow visual customisation (Note: Colour Kit footrest is shorter than standard V3i footrest!)

🛠 Compatibility 🛠
Peripherals
✔ Compatible with any Fanatec Wheel Base or Fanatec Racing Wheel with RJ12 Pedals connector. To connect Fanatec Wheels with PS/2 Pedal Socket, you need the additional PS/2 to RJ12 cable.
✔ Compatible with ClubSport Pedals V3 Brake Performance Kit
✔ Compatible with ClubSport Pedals V3 Damper Kit (Throttle Pedal)
✔ Dedicated plug for the ClubSport Handbrake
✔ The pedals are not compatible with the ClubSport USB Adapter. Please use the included USB connector (PC only).

Platforms
✔ PC:
◾ If you connect it to a Fanatec Wheel Base / Racing Wheel, it will be compatible to all racing games. For more information, check the compatibility details on the product page of the connected product.
◾ It will work with any racing wheel, also of​ any other brand (Logitech, Thrustmaster, etc), if the pedals are connected to PC via USB and if the game supports a second controller. ​These PC games support a second USB controller:
◽ iRacing
◽ Assetto Corsa
◽ Project Cars
◽ GTR 2
◽ Race 07
◽ rFactor
◽ Live for Speed
◽ ...and many others
✔ Consoles: This pedal set can be used on gaming consoles, if connected through a Fanatec Wheel Base / Racing Wheel. Further information can be found on the Fanatec Wheel Base / Racing Wheel product pages. It will not work on consoles using the direct USB Connection or a ClubSport USB Adapter.

Peripherals
✔ Compatible with any Fanatec Wheel Base or Fanatec Racing Wheel with RJ12 Pedals connector. To connect Fanatec Wheels with PS/2 Pedal Socket, you need the additional PS/2 to RJ12 cable.
✔ Compatible with ClubSport Pedals V3 Brake Performance Kit
✔ Compatible with ClubSport Pedals V3 Damper Kit (Throttle Pedal)
✔ Dedicated plug for the ClubSport Handbrake
✔ The pedals are not compatible with the ClubSport USB Adapter. Please use the included USB connector (PC only).

📍 Special Notes ‼
◾ Please note that the vibration function on gas and brake is not supported by all games. On PC it can be implemented with plugins to our driver / third party software if the games sends the telemetry data.
◾ Max resolution depends on the connection:
◽ through PWT / PWTS / CSR / CSR Elite wheel: 8-bit (256 values) on all axes
◽ through CSW B V1 / CSW B V2 / CS WB V2.5 / CSL E WB / CSL E WB+ / CSL E WB V1.1 / CSL E RW PS4: 12 bit (4096 values) / P WB DD1 & DD2 on all axes
◽ USB direct connection (PC): 12-bit (4096 values) on all axes

📦 What's included
✔ ClubSport Pedals V3 inverted
✔ ClubSport Pedals V3i Damper Kit (pre-assembled on brake pedal)
✔ 3x Pedal Extensions (2x assembled, 1x accessory)
✔ 3x D-shape pedal plates incl. mounting screws
✔ 1x Strong spring throttle
✔ 2x Stabilizer feet incl. mounting screws
✔ 1x RJ12 connection cable (150cm)
✔ 1x USB connection cable (180cm)
✔ 1x Allen Key for damper
✔ 1x Lithium grease bottle
✔ 1x Quick Guide
